Brief introduction
IGBT module, produced by STARPOWER. 1200V 400A.
Features
- Low VCE(sat) Trench IGBT technology
- 10μs short circuit capability
- VCE(sat) with positive temperature coefficient
- Maximum junction temperature 175oC
- Low inductance case
- Fast & soft reverse recovery anti-parallel FWD
- Isolated copper baseplate using DBC technology
Typical Applications
- Switching mode power supply
- Inductive heating
- Electronic welder
Absolute Maximum Ratings TC=25oC unless otherwise noted
IGBT
Symbol |
Description |
Values |
Unit |
VCES |
Collector-Emitter Voltage |
1200 |
V |
VGES |
Gate-Emitter Voltage |
±20 |
V |
IC |
Collector Current @ TC=25oC
@ TC=100oC
|
769
400
|
A |
ICM |
Pulsed Collector Current tp=1ms |
800 |
A |
PD |
Maximum Power Dissipation @ Tvj =175oC |
2272 |
W |
Diode
Symbol |
Description |
Values |
Unit |
VRRM |
Repetitive Peak Reverse Voltage |
1200 |
V |
IF |
Diode Continuous Forward Current |
400 |
A |
IFM |
Diode Maximum Forward Current tp=1ms |
800 |
A |
Module
Symbol |
Description |
Value |
Unit |
Tvjmax |
Maximum Junction Temperature |
175 |
oC |
Tvjop |
Operating Junction Temperature |
-40 to +150 |
oC |
TSTG |
Storage Temperature Range |
-40 to +125 |
oC |
VISO |
Isolation Voltage RMS,f=50Hz,t=1min |
2500 |
V |
IGBT Characteristics TC=25oC unless otherwise noted
Symbol |
Parameter |
Test Conditions |
Min. |
Typ. |
Max. |
Unit |
|
VCE(sat)
|
Collector to Emitter
Saturation Voltage
|
IC=400A,VGE=15V, Tvj=25oC |
|
1.85 |
2.30 |
V
|
IC=400A,VGE=15V, Tvj=125oC |
|
2.25 |
|
IC=400A,VGE=15V, Tvj=150oC |
|
2.35 |
|
VGE(th) |
Gate-Emitter Threshold Voltage |
IC=16.00mA,VCE=VGE, Tvj=25oC |
5.6 |
6.2 |
6.8 |
V |
ICES |
Collector Cut-Off
Current
|
VCE=VCES,VGE=0V,
Tvj=25oC
|
|
|
1.0 |
mA |
IGES |
Gate-Emitter Leakage Current |
VGE=VGES,VCE=0V, Tvj=25oC |
|
|
400 |
nA |
RGint |
Internal Gate Resistance |
|
|
0.5 |
|
Ω |
Cies |
Input Capacitance |
VCE=25V,f=100KHz, VGE=0V |
|
43.2 |
|
nF |
Cres |
Reverse Transfer
Capacitance
|
|
1.18 |
|
nF |
QG |
Gate Charge |
VGE=- 15…+15V |
|
3.36 |
|
μC |
td(on) |
Turn-On Delay Time |
VCC=600V,IC=400A, RG=2Ω, LS=45nH,
VGE=±15V,Tvj=25oC
|
|
288 |
|
ns |
tr |
Rise Time |
|
72 |
|
ns |
td(off) |
Turn-Off Delay Time |
|
314 |
|
ns |
tf |
Fall Time |
|
55 |
|
ns |
Eon |
Turn-On Switching
Loss
|
|
43.6 |
|
mJ |
Eoff |
Turn-Off Switching
Loss
|
|
12.4 |
|
mJ |
td(on) |
Turn-On Delay Time |
VCC=600V,IC=400A, RG=2Ω, LS=45nH,
VGE=±15V,Tvj=125oC
|
|
291 |
|
ns |
tr |
Rise Time |
|
76 |
|
ns |
td(off) |
Turn-Off Delay Time |
|
351 |
|
ns |
tf |
Fall Time |
|
88 |
|
ns |
Eon |
Turn-On Switching
Loss
|
|
57.6 |
|
mJ |
Eoff |
Turn-Off Switching
Loss
|
|
17.1 |
|
mJ |
td(on) |
Turn-On Delay Time |
VCC=600V,IC=400A, RG=2Ω, LS=45nH,
VGE=±15V,Tvj=150oC
|
|
293 |
|
ns |
tr |
Rise Time |
|
78 |
|
ns |
td(off) |
Turn-Off Delay Time |
|
365 |
|
ns |
tf |
Fall Time |
|
92 |
|
ns |
Eon |
Turn-On Switching
Loss
|
|
62.8 |
|
mJ |
Eoff |
Turn-Off Switching
Loss
|
|
18.6 |
|
mJ |
|
ISC
|
SC Data
|
tP≤10μs,VGE=15V,
Tvj=150oC,VCC=800V, VCEM≤1200V
|
|
1500
|
|
A
|
Diode Characteristics TC=25oC unless otherwise noted
Symbol |
Parameter |
Test Conditions |
Min. |
Typ. |
Max. |
Units |
|
VF
|
Diode Forward
Voltage
|
IF=400A,VGE=0V,Tvj=25oC |
|
1.85 |
2.30 |
V
|
IF=400A,VGE=0V,Tvj=125oC |
|
1.90 |
|
IF=400A,VGE=0V,Tvj=150oC |
|
1.95 |
|
Qr |
Recovered
Charge
|
VR=600V,IF=400A,
-di/dt=4130A/μs,VGE=- 15V, LS=45nH,Tvj=25oC
|
|
38.8 |
|
μC |
IRM |
Peak Reverse
Recovery Current
|
|
252 |
|
A |
Erec |
Reverse Recovery Energy |
|
11.2 |
|
mJ |
Qr |
Recovered
Charge
|
VR=600V,IF=400A,
-di/dt=3860A/μs,VGE=- 15V, LS=45nH,Tvj=125oC
|
|
61.9 |
|
μC |
IRM |
Peak Reverse
Recovery Current
|
|
255 |
|
A |
Erec |
Reverse Recovery Energy |
|
18.7 |
|
mJ |
Qr |
Recovered
Charge
|
VR=600V,IF=400A,
-di/dt=3720A/μs,VGE=- 15V, LS=45nH,Tvj=150oC
|
|
75.9 |
|
μC |
IRM |
Peak Reverse
Recovery Current
|
|
257 |
|
A |
Erec |
Reverse Recovery Energy |
|
20.5 |
|
mJ |
Module Characteristics TC=25oC unless otherwise noted
Symbol |
Parameter |
Min. |
Typ. |
Max. |
Unit |
LCE |
Stray Inductance |
|
|
20 |
nH |
RCC’+EE’ |
Module Lead Resistance, Terminal to Chip |
|
0.35 |
|
mΩ |
RthJC |
Junction-to-Case (per IGBT)
Junction-to-Case (per Diode)
|
|
|
0.066
0.115
|
K/W |
|
RthCH
|
Case-to-Heatsink (per IGBT)
Case-to-Heatsink (per Diode)
Case-to-Heatsink (per Module)
|
|
0.031
0.055
0.010
|
|
K/W |
M |
Terminal Connection Torque, Screw M6 Mounting Torque, Screw M6 |
2.5
3.0
|
|
5.0
5.0
|
N.m |
G |
Weight of Module |
|
300 |
|
g |
